CPU
|
AMD Socket AM2+ / AM2 Processors
for AMD Phenom™ FX / Phenom / Athlon™ / Sempron™
AMD Cool'n'Quiet™ Technology
Support up to 140W CPU
Support 45nm Phenom™ II CPU
|
|
Chipset
|
NVIDIA GeForce 8300
|
|
System Bus
|
Up to 5200 MT/s HyperTransport™ 3.0 interface for AM2+ CPU
2000/1600 MT/s for AM2 CPU
|
|
Memory
|
4 x DIMM, Max. 8 GB, DDR2 1066/800/667 ECC,Non-ECC,Un-buffered Memory
Dual Channel memory architecture
* DDR2 1066 is supported by AM2+ CPU for one DIMM per channel only.
* Refer to www.asus.com or user manual for Memory QVL (Qualify Vendor List)
* When installing total memory of 4GB capacity or more, Windows® 32-bit operation system may only recognize less than 3GB. Hence, a total installed memory of less than 3GB is recommended.
|
|
Expansion Slots
|
1 x PCIe x16
1 x PCIe x1
2 x PCI 2.2
|
|
VGA
|
Integrated NVIDIA GeForce® 8 Series GPU
Hybrid SLI™ Support (supports Windows Vista only)
Supports HDMI™ Technology with max. resolution up to 1920 x 1200
Supports DVI with max. resolution up to 1920 × 1200 @ 60 Hz
Supports D-Sub with max. resolution up to 1920 × 1440 @ 75 Hz
HDMI/DVI/RGB Support
Supports Microsoft® DirectX 10, OpenGL 2.0, Pixel Shader 4.0
Support PCIe 2.0 / 1.0 Architecture
|
|
Storage
|
NVIDIA® GeForce 8300
1 xUltraDMA 133/100/66/33
1 xExternal SATA 3 Gb/s ports 5 x SATA 3Gb/s ports (Use SATA1-3 for IDE mode.)
NVIDIA® MediaShield™ RAID Support RAID 0,1,0+1,5,JBOD
|
|
LAN
|
NVIDIA built-in Gigabit MAC with external Realtek PHY
|
|
Audio
|
Realtek® ALC1200 8 -Channel High Definition Audio CODEC
Optical S/PDIF out port at back I/O
Support Jack Detection and Multi-streaming
DTS Surround Sensation UltraPC
|
|
IEEE 1394
|
JMB381 controller supports 2 x 1394a ports (one at midboard; one at back panel)
|
|
USB
|
12 USB 2.0 ports (6 ports at mid-board, 6 ports at back panel)
|
|
ASUS Unique Features
|
ASUS Express Gate
- Web browser, file downloading and uploading*
- Further free features upgradable
* File downloading and uploading through USB devices only
ASUS Quiet Thermal Solution
- ASUS Q-Fan
- 4+1 Phases ASUS Power Design
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
|
|
Overclocking Features
|
Precision Tweaker
- vCore: 4-step CPU voltage control
- vDIMM: Adjustable DRAM voltage at 0.00625V increment
- vChipset: 4-step Chipset voltage control
GPU Overclocking
Stepless Frequency Selection (SFS)
- SB tuning up to 300MHz at 1MHz increment
Overclocking Protection:
- ASUS CPU Parameter Recall (C.P.R.)
|
|
Special Features
|
ASUS MyLogo 2
|
|
Back Panel I/O Ports
|
1 x PS/2 Keyboard/ Mouse
1 x HDMI port
1 x DVI port
1 x D-Sub port
1 x RJ45 port
1 x External SATA port
6 x USB 2.0/1.1
1 x Optical S/PDIF output
1 x IEEE 1394a
8-Channel Audio I/O
|
|
Internal I/O Connectors
|
1 x High Definition front panel audio connector
1 x IDE connector
1 x Floppy disk drive connector
1 x CD audio-in connector
1 x CPU fan connector
1 x Chassis fan connector
1 x Power fan connector
1 x COM connector
1 x LPT connector
1 x IEEE 1394a connector
5 x SATA connectors
1 x S/PDIF Out header
3 x USB 2.0 connectors for 6 additional USB 2.0 ports
1 x 24-pin EATX power connector
1 x 4-pin x ATX 12V power connector
1 x System panel connector
|
