CPU

AMD Socket AM2+ / AM2 Phenom™ FX/Phenom™/Athlon™ /Sempron™ Processors
AMD Cool 'n' Quiet™ Technology
AMD Live!™ Ready
*Support CPU up to 125W
Support 45nm Phenom™ II CPU

Chipset

NVIDIA GeForce 8300

System Bus

Up to 5200 MT/s HyperTransport™ 3.0 interface for AM2+ CPU
2000/1600 MT/s for AM2 CPU

Memory

4 x DIMM, Max. 8 GB, DDR2 1066/800/667 ECC,Non-ECC,Un-buffered Memory
Dual Channel memory architecture
*DDR2 1066 is supported by AM2+ CPU only
**Refer to www.asus.com or user manual for Memory QVL (Qualify Vendor List)
***When installing total memory of 4GB capacity or more, Windows® 32-bit operation system may only recognize less than 3GB. Hence, a total installed memory of less than 3GB is recommended.

Expansion Slots

1 x PCIe x16 (Support PCIe 2.0 / 1.0 Architecture )
2 x PCIe x1
3 x PCI 2.2

VGA

Integrated NVIDIA GeForce® 8 Series GPU
Hybrid SLI™ Support (supports Windows Vista only)
Supports HDMI™ Technology with max. resolution up to 1920 x 1200
Supports DVI with max. resolution up to 1920 × 1200 @ 60 Hz
Supports D-Sub with max. resolution up to 1920 × 1440 @ 75 Hz
HDMI/DVI/RGB Support
Supports Microsoft® DirectX 10, OpenGL 2.0, Pixel Shader 4.0
Support PCIe 2.0 / 1.0 Architecture
Maximum shared memory of 512MB

Storage

NVIDIA® GeForce 8300
1 xUltraDMA 133/100/66/33
6 xSATA 3 Gb/s ports (Use SATA1-4 for IDE mode.)
NVIDIA® MediaShield™ RAID Support RAID 0,1,0+1,5,JBOD

LAN

NVIDIA Gigabit MAC
Atheros® F1 Gigabit PHY featuring AI NET 2

Audio

Realtek® ALC1200 8 -Channel High Definition Audio CODEC
Coaxial S/PDIF out ports at back I/O
Support Jack Detection and Multi-streaming

IEEE 1394

LSI® FW322 controller supports 2 x 1394a ports

USB

12 USB 2.0 ports (6 ports at mid-board, 6 ports at back panel)

ASUS Unique Features

ASUS Express Gate Lite
- Web browser, file downloading and uploading*
- Further free features upgradable
* File downloading and uploading through USB devices only
ASUS Quiet Thermal Solution
- ASUS AI Gear 2
- ASUS AI Nap
- ASUS Q-Fan 2
- 4+1 Phases ASUS Power Design
ASUS Crystal Sound
- ASUS Noise Filter
ASUS EZ DIY
- ASUS Q-Connector
- ASUS Q-Shield
- ASUS EZ Flash 2

Overclocking Features

Intelligent overclocking tools
- AI Overclocking (intelligent CPU frequency tuner)
- ASUS AI Booster Utility
Precision Tweaker
- vDIMM: 8 -step DRAM voltage control
- vCore: Adjustable CPU voltage at 0.0125V increment
- vChipset 4-step Chipset voltage control
SFS (Stepless Frequency Selection)
- FSB tuning from 200MHz to 600MHz at 1MHz increment
- Memory tuning from 533MHz up to 1066MHz
- PCI Express frequency tuning from 100MHz up to 200MHz at 1MHz increment
Overclocking Protection
- ASUS C.P.R.(CPU Parameter Recall)

Special Features

ASUS MyLogo 2
Uses 100% All High-quality Conductive Polymer Capacitors!

Back Panel I/O Ports

1 x PS/2 Keyboard
1 x S/PDIF Out
1 x IEEE 1394a
1 x LAN(RJ45) port
6 x USB 2.0/1.1
8 -Channel Audio I/O
1 x HDMI

Internal I/O Connectors

3 x USB connectors support additional 6 USB ports
1 x Floppy disk drive connector
1 x IDE connector
1 x COM connector
1 x VGA connector
6 x SATA connectors
1 x CPU Fan connector
1 x Chassis Fan connector
1 x Power Fan connector
Front panel audio connector
1 x S/PDIF Out Header
1 x IEEE1394a connector
Chassis Intrusion connector
CD audio in
24-pin ATX Power connector
4-pin ATX 12V Power connector
System Panel
