Intel® Socket 775 Core™2 Quad/Core™2 Extreme/Core™2 Duo/Pentium® dual-core/Celeron® dual-core /Celeron® Processors
Support Intel® 45nm Multi-Core CPU
Intel® Hyper-Threading Technology ready
Support Enhanced Intel SpeedStep Technology (EIST)
*Refer to www.asus.com for Intel CPU support list
|
| Chipset |
Intel® G41 / ICH7 |
| Front Side Bus |
1333/1066/800 MHz |
| Memory |
2 x DIMM, Max. 8 GB, DDR3 1333(O.C.)/1066/800 Non-ECC,Un-buffered Memory
Dual Channel memory architecture
**Refer to www.asus.com or user manual for Memory QVL (Qualify Vendor List) |
| Expansion Slots |
1 x PCIe x16
1 x PCIe x1
2 x PCI
|
| VGA |
Integrated Intel GMA X4500 graphics
Supports HDMI with max. resolution 1920X1080(@ 60Hz)
Supports RGB with max. resolution 2048 x 1536 (@75Hz)
Supports Microsoft® DirectX® 10 |
| Storage |
Southbridge
1 x UltraDMA 100/66/33
4 x SATA 3 Gb/s ports |
| LAN |
PCIE Gb LAN |
| Audio |
ALC887 8-Channel High-Definition Audio CODEC
*Choose the chassis with HD audio module in front panel to support 8-Channel audio output |
| USB |
6 x USB 2.0/1.1 ports (4 ports at mid-board, 2 ports at the back panel)
2 x USB 3.0/2.0 ports (blue, at the back panel) |
| ASUS Unique Features |
ASUS CrashFree BIOS 3
ASUS AI NET2
ASUS Q-Fan
ASUS EZ Flash 2
ASUS MyLogo 2
ASUS Anti-Surge
ASUS Turbo Key
ASUS Express Gate
ASUS EPU 4 Engine
|
| Special Features |
100% All High-quality Conductive Polymer Capacitors |
| Back Panel I/O Ports |
1 x VGA
1 x PS/2 Keyboard
1 x HDMI
1 x PS/2 Mouse
1 x S/PDIF Out (optical)
1 x LAN(RJ45) port
2 x USB 3.0/2.0
2 x USB 2.0/1.1
3 x Audio jacks |
| Internal I/O Connectors |
2 x USB connectors support additional 4 USB ports
1 x CPU Fan connector
1 x Chassis Fan connector
1 x Front panel audio connector
1 x S/PDIF Out connector
1 x 24-pin EATX Power connector
1 x 4-pin ATX 12V Power connector
4 x Serial ATA connectors
1 x System Panel connector
1 x IDE connector
1 x Parallel port
1 x COM
|
| BIOS |
8 Mb Flash ROM , AMI BIOS, PnP, DMI 2.0, Wfm2.0, ACPI 2.0a, SMBIOS 2.5
|
| Manageability |
WOL, PXE, WOR by Ring, PME Wake Up |
| Accessories |
User manual
1 x I/O Shield
1 x UltraDMA 100/66/33 cable
2 x SATA cable(s) |
| Support Disc |
Drivers
ASUS PC Probe II
Anti-virus software (OEM version)
ASUS Update
|
| Form Factor |
uATX Form Factor
9.6 inch x 8.2 inch ( 24.4 cm x 20.8 cm ) |
