Intel® Socket 775 Core™2 Quad/Core™2 Extreme/Core™2 Duo/Pentium® dual-core/Celeron® dual-core /Celeron® Processors
Support Intel® 45nm Multi-Core CPU
Intel Hyper-Threading Technology ready
Support Enhanced Intel SpeedStep Technology (EIST)
*Refer to www.asus.com for Intel CPU support list
Chipset
Intel® G41 / ICH7
Front Side Bus
1333/1066/800 MHz
Memory
2 x DIMM, Max. 8 GB, DDR3 1333(O.C.)/1066/800 Non-ECC,Un-buffered Memory
Dual Channel memory architecture
**Refer to www.asus.com or user manual for Memory QVL (Qualify Vendor List)
**When you install a total memory of 4GB or more, Windows® 32-bit operating system may only recognize less than 3GB. We recommend a maximum of 3GB system memory if you are using a Windows® 32-bit operating system.
Expansion Slots
1 x PCIe x16
1 x PCIe x1
2 x PCI
VGA
Integrated Intel GMA X4500 graphics
Supports HDMI with max. resolution 1920X1080(@ 60Hz)
Supports RGB with max. resolution 2048 x 1536 (@75Hz)
Supports Microsoft® DirectX® 10
ALC887 8-Channel High-Definition Audio CODEC
*Choose the chassis with HD audio module in front panel to support 8-Channel audio output
USB
8 USB 2.0/1.1 ports (4 ports at mid-board, 4 ports at back panel)
ASUS Unique Features
ASUS CrashFree BIOS 3
ASUS AI NET2
ASUS Q-Fan
ASUS EZ Flash 2
ASUS MyLogo 2
ASUS Anti-Surge
ASUS Turbo Key
ASUS Express Gate
ASUS EPU 4 Engine
Back Panel I/O Ports
1 x VGA
1 x PS/2 Keyboard
1 x HDMI
1 x PS/2 Mouse
1 x S/PDIF Out (optical)
1 x LAN(RJ45) port
4 x USB 2.0/1.1
3 x Audio jacks
Internal I/O Connectors
2 x USB connectors support additional 4 USB ports
1 x IDE connector
4 x SATA connectors
1 x CPU Fan connector
1 x Chassis Fan connector
1 x Front panel audio connector
1 x S/PDIF Out connector
1 x 24-pin EATXPWR Power connector
1 x 4-pin ATX 12V Power connector
1 x System Panel connector
1 x Parallel port
1 x COM
BIOS
8 Mb Flash ROM , AMI BIOS, PnP, DMI 2.0, Wfm2.0, ACPI 2.0a, SMBIOS 2.5
