| CPU |
- Support for Socket AM2+/ AM2 processors: AMD Phenom™ FX processor/ AMD Phenom™ X4 processor/ AMD Phenom™ X3 processor/ AMD Athlon™ X2 processor/ AMD Athlon™ processor/ AMD Sempron™ X2 processor/ AMD Sempron™ processor
|
| Hyper Transport Bus |
- 5200/2000 MT/s
|
| Chipset |
- North Bridge: AMD 790GX
- South Bridge: AMD SB750
|
| Memory |
- 4 x 1.8V DDR2 DIMM sockets supporting up to 16 GB of system memory (Note 1)
- Dual channel memory architecture
- Support for DDR2 1066 (Note 2)/800/667 MHz memory modules
|
| Integrated Memory |
- 128MB DDR3 SidePort memory
|
| Audio |
- Realtek ALC889A codec
- High Definition Audio
- 2/4/5.1/7.1-channel
- Support for Dolby® Home Theater (Note 3)
- Support for S/PDIF In/Out
- Support for CD In
|
| LAN |
- Realtek 8111C chip (10/100/1000 Mbit)
|
| Expansion Slots |
- 1 x PCI Express x16 slot, running at x16 (PCIEX16_1) (Note 4)
- 1 x PCI Express x16 slot, running at x8 (PCIEX8_1)
(The PCIEX16_1 and PCIEX8_1 slots support ATI Hybrid CrossFireX technology, ATI CrossFireX technology and conform to PCI Express 2.0 standard.)
- 3 x PCI Express x1 slots
- 2 x PCI slots
|
| Storage Interface |
South Bridge:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
- 6 x SATA 3Gb/s connectors supporting up to 6 SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1, RAID5, RAID 10 and JBOD
iTE IT8718 chip:
1 x floppy disk drive connector supporting up to 1 floppy disk drive
|
| IEEE 1394 |
T.I. TSB43AB23 chip
- Up to 3 IEEE 1394a ports (1 on the back panel, 2 via the IEEE 1394a bracket connected to the internal IEEE 1394a header)
|
| USB |
Integrated in the South Bridge
- Up to 12 USB 2.0/1.1 ports (4 on the back panel, 8 via the USB brackets connected to the internal USB headers)
|
| Internal I/O Connectors |
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 1 x floppy disk drive connector
- 1 x IDE connector
- 6 x SATA 3Gb/s connectors
- 1 x CPU fan header
- 2 x system fan header
- 1 x power fan header
- 1 x front panel header
- 1 x front panel audio header
- 1 x CD In connector
- 1 x S/PDIF In/Out header
- 2 x IEEE 1394a header
- 4 x USB 2.0/1.1 headers
- 1 x parallel port header
- 1 x serial port header
- 1 x chassis intrusion header
- 1 x power LED header
|
| Back Panel Connectors |
- 1 x PS/2 keyboard port
- 1 x PS/2 mouse port
- 1 x D-Sub port
- 1 x DVI-D port (Note 5)
- 1 x HDMI port
- 1 x optical S/PDIF Out connector
- 1 x IEEE 1394a port
- 4 x USB 2.0/1.1 ports
- 1 x RJ-45 port
- 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone)
|
| H/W Monitoring |
System voltage detection
- CPU/System temperature detection
- CPU/System fan speed detection
- CPU overheating warning
- CPU/System fan fail warning
- CPU/System fan speed control (Note 5
|
